Basic Info.
Model NO.
Kwikstage scaffolding
Supporting Mode
Projecting Scaffolding
Lapping Form
Double Scaffolding
Erection Position
External Scaffolding
Scaffolding Part Type
Scaffolding Couplers
Construction Properties
Building Scaffold
Surface Treatmer
Hot Dipped Galvanized/Painting
Certification
AS/NZS 1576/1577
Transport Package
Steel Pallet
Specification
3.6m/3.2m/2.7m/2.1m/1.7m
Trademark
ADTO
Origin
Tianjin, China
Production Capacity
1000 Ton/Tons Per Month
Product Description
Kwikstage scaffolding can be fastened once connected, so it is also called quickstage scaffolding system due to its speedy installation. Kwikstage Scaffolding is the one of the best scaffolding systems, reliable in Australia for its flexibility, strength and easy of installation.
This scaffolding system saves erection and dismantling time, reducing labour costs and creating time for what matters most -getting the job done!
Main Componets:
Kwikstage standard
Material: Q235, 48.3*4mm
Length: 0.5m, 1.0m, 1.5m, 2.0m, 2.5m, 3.0m
Surface finish: Painted/Galvanized
Standard: AS/NZS 1576
Kwikstage Ledger
Material: Q235, 48.3*3.2mm
Length: 0.5m, 0.7m, 0.8m, 1.0m, 1.2m, 1.8m, 2.4m, 3.0m
Surface finish: Painted/Galvanized
Standard: AS/NZS 1576
Kwikstage Transom
Material: Q235, 50*50*5mm
Length: 0.5m, 0.7m, 0.8m, 1.0m, 1.2m, 1.8m, 2.4m.
Surface finish: Painted/Galvanized
Standard: AS/NZS 1576
Kwikstage Diagonal Brace
Material: Q235, 48.3*3.2mm
Length: 1.7m, 2.1m, 2.7m, 3.2m, 3.6m
Surface finish: Painted/Galvanized
Standard: AS/NZS 1576
Kwikstage Tie Bar
Material: Q235, 40*40*4mm
Length: 0.5m, 0.7m, 1.0m, 1.2m, 1.8m, 2.4m
Surface finish: Painted/Galvanized
Standard: AS/NZS 1576
Kwikstage Steel Board
Material: 230*63mm
Length: 0.54m, 0.74m, 1.03m, 1.25m, 1.81m, 2.42m, 3.07m
Surface finish: Painted/Galvanized
Standard: AS/NZS 1577
Packaging & Delivery:
Packaging Details
wooden pallet, steel pallet, or as the requirment of clients
Port:Tianjin port
Lead Time:
wooden pallet, steel pallet, or as the requirment of clients
Port:Tianjin port
Lead Time:
| Quantity(metric tons) | 1 - 500 | >500 |
| Est. Time(days) | 30 | To be negotiated |
Company Profile:
About Us
ADTO group was established in 1998. It's a building materials supplier integrating R&D, production, sales and logistics. Its products include all kinds of scaffoldings, all types of formworks. For these products, ADTO owns 4 advanced manufacturing bases, equipped with top line machines in Tianjin, Hubei and other two Provinces.
Quality and safety builds future is ADTO Group's belief. Since the foundation of our group company, we have rapidly grown to be the scaffolding & aluminum formwork leading brand in China with more than 50 national patents.
Showroom:
Production Line:
Exhibition Experience:
Certification:
Our Advantages:
a) Durability: Kwikstage scaffold is made of tough material and provides long-term benefits.
b) Adaptability: It is adaptable to different construction sites and all types of buildings.
c) Increased productivity: it can sustain many workers at the same time, thereby increasing productivity.
d) Lower maintenance costs: It does not require costly maintenance.
e) No loose fittings: the wedgelock system without any screws or nuts
f) Labor saving: it can be erected and dismantled easily and fast.
